| Producer | Traub |
| Year manufacture | 2008 |
| Control system | Traub TX 8 i |
| Turn table diameter | 680 mm |
| Turning lenght | 1000 mm |
| Spindle bore | 100 mm |
| Number of tool positions (driven) | 12/12 |
| Travel X-axis | 320 mm |
| Travel Z-axis | 1070 mm |
| Axis C | 0,001° |
| X-axis rapid feed | 15 m/min |
| Z-axis rapid feed | 20 m/min |
| Spindle speed | 1 - 2240 /min. |
| Max. torque of spindle | 682 Nm |
| Main motor power | 31 kW |
| Speed driven tools | 1 - 3150 /min. |
| Machine weight | 6800 kg |
| Machine dimensions l x w x h | 5500x2300x2150 mm |
| Control system | Traub TX 8 i |
| Turn table diameter | 680 mm |
| Turning lenght | 1000 mm |
| Spindle bore | 100 mm |
| Number of tool positions (driven) | 12/12 |
| Travel X-axis | 320 mm |
| Travel Z-axis | 1070 mm |
| Axis C | 0,001° |
| X-axis rapid feed | 15 m/min |
| Z-axis rapid feed | 20 m/min |
| Spindle speed | 1 - 2240 /min. |
| Max. torque of spindle | 682 Nm |
| Main motor power | 31 kW |
| Speed driven tools | 1 - 3150 /min. |
| Machine weight | 6800 kg |
| Machine dimensions l x w x h | 5500x2300x2150 mm |
| Dismantling | Not Included |
| Loading | Not Included |
| Inspections | By appoitment |
| Country: | Czech Republic |
| Address: | No street selected |
