Description

Doosan robotic cell assembly:

2x LYNX 2100A + ROBOTEC APC7 (Fanuc AM-100 iC6L)

- Machines are equipped with chucks and collets.

- High pressure cooling 20bar

- Workpiece arm for picking Ø65 x L130 mm, weight 3 Kg)

- Automatic door opening

- Spindle blowing for cleaning the chuck jaws

- Oil separator - OIL SKIMMER

- Tool Load Monitor (works with X, Z axis and S spindle)

- Workpiece Conveyor

Producer
Doosan
Year manufacture
2017
Control system
Fanuc i Series
Turn table diameter
600 mm
Turning lenght
330 mm
Sloping bed
Yes
Spindle bore61 mm
Swing over bed
600 m
Swing over cross slide
400 mm
Travel X-axis
205 mm
Travel Z-axis
340 mm
X-axis rapid feed
30 m/min.
Z-axis rapid feed
36 m/min.
Spindle speed
0 - 6000 /min.
Max. torque of spindle
127 Nm
Main motor power
11/15 kW

Technical parameters

Control system Fanuc i Series
Turn table diameter 600 mm
Turning lenght 330 mm
Sloping bed Yes
Spindle bore 61 mm
Turret head Yes
Swing over bed 600 mm
Swing over cross slide 400 mm
Travel X-axis 205 mm
Travel Z-axis 340 mm
X-axis rapid feed 30 m/min.
Z-axis rapid feed 36 m/min.
Spindle speed 0 - 6000 /min.
Max. torque of spindle 127 Nm

Doosan

Condition The machine is in excelent condition. Possible to test under power.
Dismantling Included
Loading Included
Inspections By appoitment
Country: Czech Republic
Address: No street selected
